CPU: AMD Geode LX800 500MHz processor Cache Memory 64K I/ 64k D L1 cache, 128K L2 cache
System Chipset: AMD CS5536
BIOS: AWARD
System Memory:
1 x 200-pin DDR 400/333MHz SO-DIMM SDRAM socket support up to 1GB
Ethernet LAN: 10/100Base-T dual RTL8100C
I/O by Super I/O W83627HG
- 4 x USB 2.0
- 2 x SATA-150
- 1 x CFII
- 1 x LPT
- 6 x RS-232, 1 x RS-422/485
- 1 x PS/2 keyboard/mouse
- 1 x IDE
- Digital I/O - 4 input / 4 output
Audio: AC’97 Codec Realtek ALC203
Display: CRT integrated in AMD Geode LX800
- TTL 24-bit single channel TTL integrated in AMD Geode LX800
- 18-bit single channel LVDS integrated in AMD Geode LX800
Watchdog Timer: Software programmable supports 1~255 sec. system reset
Power Supply: +12V only, AT/ATX support
Power Consumption:
+12V@ 0.92A (AMD LX 800 with DDR 400MHz 256MB RAM)
Temperature Operation: 0 ~ 60º (32 ~ 140ºF)
Humidity Operation: 5% ~ 95%
Dimensions: 115 mm x 165 m
Weight: GW: 950g; Net W: 350g
|
