Specifications:

CPU

Intel P4, Prescott and Celeron

CPU speed

Up to 3.2 GHz

FSB speed

Supports 800/533 Mhz CPU

Chipset

Intel® 865G/GV Chipset with ICH5

DRAM

2 x 184-pin DIMM for dual channel DDR333/400 up to 2GB

BIOS

Award bios

Serial ATA

2 x Serial ATA 150, RAID function optional

VGA

Built-in to the  Intel 865G/GV, Intel Extreme Graphics II, AGP 4x/8x

IDE Interface

2 x IDE ATA-100, 40 pin header

FDD Interface

1 34 pin header

Compact Flash

1 Compact Flash type II socket on board

Serial Ports

2 x RS232 by pin header

Parallel Port

1 x parallel (SPP/EPP/ECP)

Watchdog

1 to 255 seconds, selectable for system reset

Keyboard

Shares one Mini DIN connector with mouse,  Y cable adapter supplied

Mouse

Shares one Mini DIN connector with keyboard, Y cable adapter supplied

Speaker

On board piezo

IrDA

1 x IrDA (SIR) serial infrared interface

LAN

Intel® 82562ET10/100 Mbps Ethernet, Wake-on-LAN with ATX power supply

USB

8 x USB 2.0, by pin headers

Sound

AC '97 Codec

Bus Interface

ISA/PCI (PICMG spec)

Power Requirement

+5v@6.98A, +12v@7.52A, -12v@0.5A (P4, 3 Ghz, 800 Mhz, 512 Mb dual DDR400

Hardware Monitor

Voltage, CPU temp. & cooling fan

Operating Temp.

0-60 deg. C

Relative Humidity

5 to 95% non condensing

Dimension

338.5mm x 122mm, 13.33" x 4.8"

Weight

Shipping weight = 3lbs (1.1kg)
