Specifications
|
AFL-07A-LX
|
AFL-08A-LX
|
AFL-10A-LX
|
AFL-12A-LX
|
|
More Info
|
Data Sheet
|
Data Sheet
|
Data Sheet
|
Data Sheet
|
|
LCD size
|
7”
|
8.4”
|
10.4”
|
12.1”
|
|
LCD brightness
|
220 nits (cd/m2)
|
450 nits
|
400 nits
|
450 nits
|
|
Max resolution
|
800 x 480
|
800 x 600
|
800 x 600
|
1024 x768
|
|
Contrast ratio
|
400:1
|
500:1
|
500:1
|
700:1
|
|
Max Colors
|
262 K
|
262 K
|
262 K
|
262 K
|
|
Pixel Pitch - mm
|
0.1905(H) x0.1905(V)
|
0.213(H) x 0.213(V)
|
211.2(H) x 158.4(V)
|
0.240(H) x 0.240(V)
|
|
Viewing Angle H/V
|
140/ 100
|
130/110
|
120/100
|
160/160
|
|
CPU
|
AMD LX800-500Mhz
|
AMD LX800-500Mhz
|
AMD LX800-500Mhz
|
AMD LX800-500Mhz
|
|
Chipset
|
AMD LX800 + CS5536
|
AMD LX800 + CS5536
|
AMD LX800 + CS5536
|
AMD LX800 + CS5536
|
|
System Memory
|
Max = 1GB SODIMM - DDR333/400 256 or 512 mb is standard
|
Max = 1GB SODIMM - DDR333/400 256 or 512 mb is standard
|
Max = 1GB SODIMM - DDR333/400 256 or 512 mb is standard
|
Max = 1GB SODIMM - DDR333/400 256 or 512 mb is standard
|
|
Hard Drive
|
Compact Flash CFII solid state disk
|
Compact Flash CFII solid state disk
|
Compact Flash CFII solid state disk
|
Compact Flash CFII solid state disk or 2.5” hard drive
|
|
CD or DVD drive
|
None- use external USB drive
|
None- use external USB drive
|
None- use external USB drive
|
None- use external USB drive
|
|
Touchscreen
|
Resistive, 4-Wire
|
Resistive, 4-Wire
|
Resistive, 5 wire
|
Resistive, 5-Wire
|
|
LAN
|
2 x LAN 10/100Mbps ports RJ45 connector, RTL8100C
|
2 x LAN 10/100Mbps ports RJ45 connector, RTL8100C
|
2 x LAN 10/100Mbps ports RJ45 connector, RTL8100C
|
2 x LAN 10/100Mbps ports, RJ45 connector, RTL8100C
|
|
Wi Fi
|
Yes, 802.11b/g
|
Yes, 802.11b/g
|
Yes, 802.11b/g
|
Yes, 802.11b/g
|
|
USB ports
|
2 x USB 2.0
|
2 x USB 2.0
|
2 x USB 2.0
|
2 x USB 2.0
|
|
Serial ports
|
1 x RS232 and 1 RS232/RS422/RS485
|
1 x RS232 and 1 RS232/RS422/RS485
|
1 x RS232 and 1 RS232/RS422/RS485
|
1 x RS232 and 1 RS232/RS422/RS485
|
|
Printer port
|
Not available - use USB
|
Not available - use USB
|
Not available - use USB
|
Not available - use USB
|
|
Audio
|
2 x internal speakers
|
2 x internal speakers
|
2 x internal speakers
|
2 x internal speakers
|
|
Keyboard/Mouse
|
Not available - use USB
|
Not available - use USB
|
Not available - use USB
|
Not available - use USB
|
|
Expansion slot
|
1x Mini PCI used for Wireless Lan 802.11b/g
|
1x Mini PCI used for Wireless Lan 802.11b/g
|
1x Mini PCI used for Wireless Lan 802.11b/g
|
1x Mini PCI used for Wireless Lan 802.11b/g
|
|
Bluetooth module
|
Yes
|
Yes
|
Yes
|
Yes
|
|
Watchdog
|
Yes
|
Yes
|
Yes
|
Yes
|
|
Power required
|
12 vdc @1.66A, 20 watts
|
12 vdc @1.66 A, 20 watts
|
12 vdc @ 2 A, 25 watts
|
12 vdc @2,4 A, 29 watts
|
|
External AC Adapter
|
External 45W AC adapter Input:90~260VAC@ 50/60Hz - Output:12VDC
|
External 45W AC adapter Input:90~260VAC@ 50/60Hz - Output:12VDC
|
External 45W AC adapter Input:90~260VAC@ 50/60Hz - Output:12VDC
|
External 45W AC adapter Input:90~260VAC@ 50/60Hz - Output:12VDC
|
|
Construction
|
ABS Plastic case with Aluminum chassis
|
ABS Plastic case with Aluminum chassis
|
ABS Plastic case with Aluminum chassis
|
ABS Plastic case with Aluminum chassis
|
|
Front Panel
|
Waterproof and Dustproof IP 64 rating, Black color
|
Waterproof and Dustproof IP 64 rating, Black color
|
Waterproof and Dustproof IP 64 rating, Gray color
|
Waterproof and Dustproof IP 64 rating, Black color
|
|
Indicators & switches
|
Power LED / Power sw, reset button
|
Power LED / Power sw, reset button
|
Power LED / Power sw, reset button
|
Power LED / Power sw, reset button
|
|
Dimensions(WxHxD)
|
226 x 140 x 40.2 mm
|
233.9x 183.9 x 41.1mm
|
276 x 226.9 x 50.7 mm
|
304 x 246 x 49.5 mm
|
|
Weight
|
1.32 lbs or 0.6 kg
|
1.76 lbs or 0.8 kg
|
3.1 lbs or 1.4kg
|
4 lbs or 1.8 kg
|
|
Temperature
|
Operating = 0 to 50 C Storage = -20 to 60 C
|
Operating = 0 to 50 C Storage = -20 to 60 C
|
Operating = 0 to 50 C Storage = -20 to 60 C
|
Operating = 0 to 50 C Storage = -20 to 60 C
|
|
Vibration rating
|
5~17Hz 0.1 double amplitute displacement -17~640 Hz 1.5G acceleration peak
to peak
|
5~17Hz 0.1 double amplitute displacement -17~640 Hz 1.5G acceleration peak
to peak
|
5~17Hz 0.1 double amplitute displacement -17~640 Hz 1.5G acceleration peak
to peak
|
5~17Hz 0.1 double amplitute displacement -17~640 Hz 1.5G acceleration peak
to peak
|
|
Shock rating
|
Shock 10G acceleration peak to peak (11ms)
|
Shock 10G acceleration peak to peak (11ms)
|
Shock 10G acceleration peak to peak (11ms)
|
Shock 10G acceleration peak to peak (11ms)
|
|
Mounting options
|
Panel / Wall / Rack / Stand / Arm mounting
|
Panel / Wall / Rack / Stand / Arm mounting
|
Panel / Wall / Rack / Stand / Arm mounting
|
Panel / Wall / Rack / Stand / Arm mounting
|
|
Standards
|
RoHS, Safety Complies with UL, CE and CCC and EMC Complies with CE and FCC Class B
|
RoHS, Safety Complies with UL, CE and CCC and EMC Complies with CE and FCC Class B
|
RoHS, Safety Complies with UL, CE and CCC and EMC Complies with CE and FCC Class B
|
RoHS, Safety Complies with UL, CE and CCC and EMC Complies with CE and FCC Class B
|
|
Compatible OS
|
Windows XP embedded, Windows CE 5, Linux (Fedora Core 6 and 7)
|
Windows XP embedded, Windows CE 5, Linux (Fedora Core 6 and 7)
|
Windows XP embedded, Windows CE 5, Linux (Fedora Core 6 and 7)
|
Windows XP embedded Windows CE 5, Linux (Fedora Core 6 and 7)
|
